5.
CAUTION:
• Do not lose the 2 spacers of the Contact Image Sensor Unit.
• Do not touch the document reading part [A] of the Contact Image Sensor Unit.
Removing the Contact Image Sensor (Copyboard Model)
■ Preparation
1. “Removing the Cartridge” on page 77
2. “ Removing the Left Cover” on page 80
3. “Removing the Copyboard Cover” on page 157
4. “Removing the Copyboard Cover + Reader Unit” on page 157
5. “Removing the Platen Glass (Copyboard Model)” on page 161
4. Parts Replacement and Cleaning
163
