TESTMODE (Service mode for test print, operation check, etc.) > FAX (FAX test mode) > FACULTY
DETECT1 Ring detection
Detail To check Ci of the I line, Fc and the status of hook (ON/OFF).
Display/Adj/Set Range
Select the item
Supplement/Memo
Fax model only
DETECT2 CNG detection test 1
Detail To execute CNG signal check and FED check.
To detect CNG while CML relay is ON.
Display/Adj/Set Range
Select the item
Supplement/Memo
Fax model only
DETECT3 CNG detection test 2
Detail To execute CNG signal check and FED check.
To detect CNG while CML relay is OFF.
Display/Adj/Set Range
Select the item
Supplement/Memo
Fax model only
PANEL (PANEL Test Mode)
TESTMODE (Service mode for test print, operation check, etc.) > PANEL (PANEL Test Mode)
KEY CHECK START Key check
Detail To check for any failure of the keys.
Adj/Set/Operate Method
By pressing a key, the corresponding character is hidden in response to the key operation.
Caution
Only the keys controlled by the Main Controller PCB are checked. The Power Switch is not
checked.
Display/Adj/Set Range
Corresponding character is displayed on the key.
LED CHECK START LED check
Detail To check for any failure of the LEDs.
Adj/Set/Operate Method
LED at the Control Panel is turned ON after items are selected. LED is turned OFF by pressing
the Start key.
Caution
Only the LEDs controlled by the Main Controller PCB are checked. The Power Supply Led is not
checked.
Display/Adj/Set Range
LEDs at Control Panel is turned ON.
LCD CHECK START LCD check
Detail To check for any failure of the LCD.
Adj/Set/Operate Method
Screen confirmation pattern is displayed after the item is selected. Pattern is changed by pressing
the Start key.
TOUCH CHECK START Touch Panel check
Detail To check for any failure of the Touch Panel.
Adj/Set/Operate Method
Press 5 displayed rectangles in order after selecting the item.
Supplement/Memo
Only for Touch Panel model.
