FAX (FAX service mode)
SSSW (Bit switch registration mode)
SSSW No. Bit No. Function
SW 01 (Related to error and copy function)
Bit 0 Error code output for service technician
Bit 1 Error memory dump
Bit 2 to Bit 7 Not used
SW 02 (Related to settings for network connection condition)
Bit 0 to Bit 6 Not used
Bit 7 Connect the terminal as F network type 2
SW 03 (Related to echo prevention)
Bit 0 TCF EQM check
Bit 1 to Bit 6 Not used
Bit 7 Output 1,080 Hz before CED
SW 04 (Related to prevention of communication problems)
Bit 0 Not used
Bit 1 Check the frequency of CI signal
Bit 2 Not used
Bit 3 Prohibit T.30 node F from waiting for 2-sided
Bit 4 T.30 node F echo timer
Bit 5 Check the frequency of CI signal at PBX settings
Bit 6 CNG is not sent when sending manually
Bit 7 CED is not sent when receiving manually
SW 05 (Standard function, related to DIS signal settings)
Bit 0 to Bit 1 Not used
Bit 2 Millimeter/inch conversion (text/photo mode / photo mode)
Bit 3 Prohibit sending bit33 and after of DIS
Bit 4 Declaration of cut paper
Bit 5 to Bit 7 Not used
SW 06 (Settings for reading condition)
Bit 0 to Bit 3 Not used
Bit 4 Reading width (0: A4, 1: LTR)
Bit 5 to Bit 7 Not used
SW 07 Bit 0 to Bit 7 Not used
SW 08 Bit 0 to Bit 7 Not used
SW 09 Bit 0 to Bit 7 Not used
SW 10 Bit 0 to Bit 7 Not used
SW 11 Bit 0 to Bit 7 Not used
SW 12 (Related to page timer settings)
Bit 0 Timeout period for 1 page (sending)
Bit 1
Bit 2 Timeout period for 1 page (HT sending)
Bit 3
Bit 4 Timeout period for 1 page (receiving)
Bit 5
Bit 6 Not used
Bit 7 Timeout period for 1 page
SW 13 Bit 0 to Bit 1 Not used
Bit 2 Convert millimeter/inch when sending the received image
Bit 3 to Bit 7 Not used
SW 14 Bit 0 to Bit 1 Not used
