FEEDER (ADF service mode)
ADJUST (Adjustment mode)
FEEDER (ADF service mode) > ADJUST (Adjustment mode)
DOCST Adjust the reading start position: ADF
Detail To adjust the reading start position at ADF stream reading.
As the value is changed by 1, the margin on the leading edge of paper is changed by 0.1 mm.
+: Leading edge margin becomes smaller. (An image moves to the leading edge.)
-: Leading edge margin becomes larger. (An image moves to the trailing edge.)
Adj/Set/Operate Method
Enter the setting value, and then press OK or Apply key.
Display/Adj/Set Range
-30 to 30
Unit
0.1 mm
Default Value
0
LA-SPD Adj vertical scan magnification: ADF
Detail To adjust vertical scan magnification ratio at ADF stream reading.
As the value is changed by 1, the margin on the leading edge of paper is changed by 0.1 %.
+: Image shrinks in the vertical direction
-: Image expands in the vertical direction
Adj/Set/Operate Method
Enter the setting value, and then press OK or Apply key.
Display/Adj/Set Range
-30 to 30
Unit
0.1 %
Default Value
0
FUNCTION (Operation / inspection mode)
FEEDER (ADF service mode) > FUNCTION (Operation / inspection mode)
FEED-CHK Set read mode for ADF ppr feed chck
Detail To check paper feed of ADF only.
Display/Adj/Set Range
1/2
1: SADF
2: DADF
Related Service Mode
FEEDER > FUNCTION > FEED-ON
SL-ON Operation check of DADF solenoid
Detail To start checking operation of the DADF solenoid (SL4).
The DADF Solenoid will be ON for 0.1 second.
Adj/Set/Operate Method
The operation starts when the item is selected.
Supplement/Memo
DADF model only
MTR-ON ADF Motor operation check
Detail To check operation of the DADF Motor (M4) or SADF Motor (M5).
The motor operates for 3 to 4 seconds.
Adj/Set/Operate Method
The operation starts when the item is selected.
FEED-ON Check ADF paper feed
Detail To check paper feed of ADF only.
Adj/Set/Operate Method
The operation starts when the item is selected.
Related Service Mode
FEEDER > FUNCTION > FEED-CHK
8. Service Mode
265
