COPIER (Service mode for printer) > ADJUST (Adjustment mode) > ADJ-XY
ADJ-X-MG Fine adjust magnification: vertical scan
Detail To adjust the magnification ratio by comparing the original and the copy output sheet.
- Increase the value when the output sheet is small.
- Decrease the value when the output sheet is large.
Use Case
When the image on copy output sheet is larger or smaller than it is on the original
Adj/Set/Operate Method
Enter the setting value, and then press OK or Apply key.
Caution
This adjustment is targeted to adjust the image position on copy output. This may affect the SCAN
image.
Display/Adj/Set Range
-30 to 30
Unit
0.1 %
Default Value
0
■ CCD
COPIER (Service mode for printer) > ADJUST (Adjustment mode) > CCD
W-PLT-X Stdrd White Plt white lvl data (X) entry
Detail To enter the Standard White Plate white level data (X)
Adj/Set/Operate Method
Enter the setting value, and then press OK or Apply key.
Display/Adj/Set Range
7000 to 9999
Default Value
8493
W-PLT-Y Stdrd White Plt white lvl data (Y) entry
Detail To Enter the Standard White Plate white level data (Y)
Adj/Set/Operate Method
Enter the setting value, and then press OK or Apply key.
Display/Adj/Set Range
7000 to 9999
Default Value
8988
W-PLT-Z Stdrd White Plt white lvl data (Z) entry
Detail To enter the Standard White Plate white level data (Z)
Adj/Set/Operate Method
Enter the setting value, and then press OK or Apply key.
Display/Adj/Set Range
7000 to 9999
Default Value
9176
FBTAR-R Shading target value (R) entry
Detail To enter the shading target value of RED at copyboard reading.
Adj/Set/Operate Method
Enter the setting value, and then press OK or Apply key.
Display/Adj/Set Range
128 to 384
Default Value
297
Related Service Mode
COPIER > DISPLAY > CCD > FB-TARGET-R
FBTAR-G Shading target value (G) entry
Detail To enter the shading target value of GREEN at copyboard reading.
Adj/Set/Operate Method
Enter the setting value, and then press OK or Apply key.
Display/Adj/Set Range
128 to 384
Default Value
294
Related Service Mode
COPIER > DISPLAY > CCD > FB-TARGET-G
FBTAR-B Shading target value (B) entry
Detail To enter the shading target value of BLUE at copyboard reading.
Adj/Set/Operate Method
Enter the setting value, and then press OK or Apply key.
Display/Adj/Set Range
128 to 384
Default Value
282
Related Service Mode
COPIER > DISPLAY > CCD > FB-TARGET-B
