COPIER (Service mode for printer) > ADJUST (Adjustment mode) > CCD
FBTAR-BW Shading target value (B&W) entry
Detail To enter the shading target value of B&W at copyboard reading.
Adj/Set/Operate Method
Enter the setting value, and then press OK or Apply key.
Display/Adj/Set Range
128 to 384
Default Value
296
Related Service Mode
COPIER > DISPLAY > CCD > FB-TARGET-BW
DFTAR-R Shading target value (R) entry: ADF
Detail To enter the shading target value of RED at ADF stream reading.
Adj/Set/Operate Method
Enter the setting value, and then press OK or Apply key.
Display/Adj/Set Range
128 to 384
Default Value
354
Related Service Mode
COPIER > DISPLAY > CCD > DF-TARGET-R
Supplement/Memo
ADF model only
DFTAR-G Shading target value (G) entry: ADF
Detail To enter the shading target value of GREEN at ADF stream reading.
Adj/Set/Operate Method
Enter the setting value, and then press OK or Apply key.
Display/Adj/Set Range
128 to 384
Default Value
349
Related Service Mode
COPIER > DISPLAY > CCD > DF-TARGET-G
Supplement/Memo
ADF model only
DFTAR-B Shading target value (B) entry: ADF
Detail To enter the shading target value of BLUE at ADF stream reading.
Adj/Set/Operate Method
Enter the setting value, and then press OK or Apply key.
Display/Adj/Set Range
128 to 384
Default Value
334
Related Service Mode
COPIER > DISPLAY > CCD > DF-TARGET-B
Supplement/Memo
ADF model only
DFTAR-BW Shading target value (B&W) entry: ADF
Detail To enter the shading target value of B&W at ADF stream reading.
Adj/Set/Operate Method
Enter the setting value, and then press OK or Apply key.
Display/Adj/Set Range
128 to 384
Default Value
355
Related Service Mode
COPIER > DISPLAY > CCD > DF-TARGET-BW
Supplement/Memo
ADF model only
■ PANEL
COPIER (Service mode for printer) > ADJUST (Adjustment mode) > PANEL
TOUCHCHK Adjust coordinate position: Touch Panel
Detail To adjust the coordinate position on the Touch Panel of the Control Panel.
Use Case
When replacing the liquid crystal panel.
Adj/Set/Operate Method
Select an item, and press 5 rectangles on the display in order.
Supplement/Memo
Only for Touch Panel model.
