2.
3x
■ Assembling the DADF Moter
1. Assemble it in the following order.
[1]
[2]
[3]
[4]
[5]
[6]
[1] Separation Swing Arm
[2] Separation Gear 21T/42T
[3] Gear 17T/51T
[4] Gear 23T/46T
[5] Gear 20T
[6] DADF Motor Unit
NOTE:
Ensure that the 1 point [A] in the DADF Pickup Unit and DADF Motor Unit are in contact with the edge of the shafts.
[A]
4. Parts Replacement and Cleaning
104
