8. “ Removing the Upper Cover” on page 91
9. “ Removing the Main Fan” on page 187
10. “ Removing the NCU PCB (Fax Model)” on page 190
11. “Removing the Laser Scanner Cover” on page 192
■ Procedure
CAUTION:
Do not disassemble the Laser Scanner Unit because it requires adjustment.
1.
4. Parts Replacement and Cleaning
195
