Electric code Name
PS2 Pickup Paper Width Sensor
PS3 Top Sensor
PS4 Fixing Delivery Sensor
PS5 Fixing Paper Width Sensor
PS10 Multi-purpose Tray Sensor
PS601 Main Motor Rotation Number Sensor
■ PCB
UNIT11
UNIT12
UNIT2
UNIT8
UNIT9
UNIT7
UNIT1
UNIT4
UNIT14
UNIT17
UNIT15
UNIT16
DSP1
DSP2
Electric code Name
UNIT1 Engine Controller PCB
UNIT2 Main Controller PCB
UNIT4 Motor PCB
UNIT7 Delivery Sensor PCB
UNIT8 Top Sensor PCB
UNIT9 Environment/Pickup Sensor PCB
UNIT11 Wireless LAN PCB
UNIT12 Power Switch PCB
4. Parts Replacement and Cleaning
