Control Panel
Set./Adj. Menu
Setting Item Description, Instructions
Nozzle Check Print a test pattern to check the nozzles.
Status Print Print information about the printer .
Interface Print Print interface settings information.
GL2 Set Print Print GL2 settings information.
Paper Details Print the paper settings as specied in Paper Details .
Print Job Log Print a record of print jobs, including the paper type
and size, amount of ink consumed, and so on. Ink
consumption indicates a rough estimate of how much
ink was consumed per page.( *1 )
Menu Map Print the menu structure.
T est
Print
Color Palette Print the GL2 color palette.
Auto(Standard) The printer prints and reads a test pattern for the
automatic adjustment of Printhead alignment relative
to the printing direction.
( → P .604)
Auto(Advanced) The printer prints and reads a test pattern for the
automatic adjustment of Printhead alignment relative
to the printing direction and spacing between nozzles
and colors.
( → P .604)
Head
Posi.
Adj.
Manual Print a test pattern for adjustment of Printhead
alignment relative to the printing direction. Enter the
adjustment value manually based on the resulting
pattern.
( → P .606)
Head Inc. Adj. Print a test pattern for adjustment of the Printhead
orientation.
( → P .608)
Automatic
Print Quality
Adj.
Priority
Print Length
Specify exact paper feeding, if desired. Normally ,
select Automatic . Choose Print Quality for attractive
printing. Choosing Print Quality also makes banding
less noticeable. Choose Print Length if you prefer to
feed the paper an exact amount. However , note that
slight banding may occur in the direction of carriage
scanning when Print Length is selected.
Adjust
Printer
Feed
Priority
Adj.
Quality
Auto(GenuinePpr) Specify this mode with paper identied in the Paper
Reference Guide .
The printer prints and reads a test pattern for
automatic adjustment of the feed amount.
( → P .614)
52 Printer Parts
