7.7. Dual Mode
An installation designed to switch between Grid Connect and Stand Alone operation is identified
as Dual Mode, and must meet the installation requirements for both Grid Connect and Stand
Alone operation. Automatic transfer between modes are accomplished with the Capstone Dual
Mode System Controller (DMSC). Refer to the Dual Mode System Controller Technical Reference
(Table 1) for details.
Some locations (generally where CE systems are used), require 4-pole circuit
breakers, and a 4-pole motor-operated breaker, which will break the neutral wire
as well as the three phases. The microturbine’s neutral must be grounded at all
times in both Grid Connect and Stand Alone modes. Therefore, a neutral-
grounding relay, capable of keeping the neutral grounded when the DMSC
switches the motor-operated breaker open, is required. This construction and
theory of operation is discussed in the Dual Mode System Controller Technical
Reference (Table 1).
7.7.1. Dual Mode Connections
See Figure 50 through Figure 51 for allowable dual modes connections. The DMSC controls the
motor-operated breaker which isolates the microturbines from the grid and protected loads.
