Capstone Turbine Corporation • 16640 Stagg Street • Van Nuys • CA 91406 • USA
Installation Guide: Capstone C1000S/C800S/C600S with C1000 Series Controller
480064 Rev C (December 2018) Page 20 of 122
Capstone reserves the right to change or modify, without notice, the design, specifications, and/or contents of this document without
incurring any obligation either with respect to equipment previously sold or in the process of construction.
2.3. Rigging
Drop danger! Exercise extreme care when lifting/handling the system.
Keep all nonessential personnel clear of the lifting area at all times.
Proper rigging must be provided during lifting for stability.
If lifting at corner castings, spreader bars are required.
When lifted using fork pockets, support must be provided all the way
through.
Blanking plates must be installed during lifting. Failure to observe this caution
can result in equipment damage.
See Figure 4 for recommended lifting equipment. Refer to the O&I drawing (Table 1) for all
dimensional information, weight and center of gravity of the system. The C1000S/C800S/C600S
enclosure features a base with forklift pockets located at both sides in the center. The system can
be moved using a forklift or overhead crane provided the equipment is rated for the load. When
using a forklift, the forks must be of adequate length to support the unit. Place the forks correctly
so as to not damage the base of the unit. The system can be forked from any side when it is
completely empty or fully populated, otherwise, it must be lifted from the heavy side only. When
using a crane, ensure that all chains/cables and spreader bars are connected correctly for safe
handling. Chains/cables shall not exceed the lift angle specified by the spreader bar manufacturer.
If necessary, use guide ropes to prevent swinging and turning.
