Capstone Microturbine C1000 Series User Manual

Capstone Turbine Corporation • 16640 Stagg Street • Van Nuys • CA 91406 • USA
Installation Guide: Capstone C1000S/C800S/C600S with C1000 Series Controller
480064 Rev C (December 2018) Page 112 of 122
Capstone reserves the right to change or modify, without notice, the design, specifications, and/or contents of this document without
incurring any obligation either with respect to equipment previously sold or in the process of construction.
Table 15. External RS485 Connections at TB1
TB1 Connections
First Unit in Series
Middle Unit
Last Unit in Series
TB1-14
Jumper Installed
Jumper Removed
Jumper Removed
TB1-15
TB1-25
Jumper Installed
Jumper Removed
Jumper Removed
TB1-26
TB1-27
Jumper Installed
Jumper Removed
Jumper Removed
TB1-28
TB1-29
Jumper Removed
Jumper Removed
Jumper Installed
TB1-30
TB1-40
Jumper Removed
Jumper Removed
Jumper Installed
TB1-41
TB1-42
Jumper Removed
Jumper Removed
Jumper Installed
TB1-43
TB1-44
No Connection
RS485-A
RS485-A
TB1-45
No Connection
RS485-B
RS485-B
TB1-46
No Connection
Chassis Ground
Chassis Ground
TB1-48
RS485-A
RS485-A
No Connection
TB1-49
RS485-B
RS485-B
No Connection
