Capstone Microturbine C1000 Series User Manual

Capstone Turbine Corporation • 16640 Stagg Street • Van Nuys • CA 91406 • USA
Installation Guide: Capstone C1000S/C800S/C600S with C1000 Series Controller
480064 Rev C (December 2018) Page 35 of 122
Capstone reserves the right to change or modify, without notice, the design, specifications, and/or contents of this document without
incurring any obligation either with respect to equipment previously sold or in the process of construction.
Power connections are made using sets of 600 MCM cable (three phases plus neutral) as listed
in Table 6. The use of multiple 600 MCM cables allows bend radius to be reduced to 14 inches.
Table 6. Power Cable Sets
Turbine
Main Power Connection
Maximum Output Current
C600
3 sets 600 MCM
900 A
RMS
C800
4 sets 600 MCM
1200 A
RMS
C1000
4 or 5* sets 600 MCM
1500 A
RMS
* Fifth lug would need to be added.
4.3.3. Heater Power Connections
In a high humidity configuration, power for the heaters installed in the microturbine bays must be
externally supplied. Refer to Table 7 for heater power connection requirements. See Figure 11
for the for the heater power distribution block in the EPDB.
Table 7. Heater Power Connections
Parameter
Specifications
Input Voltage
110 to 240 VAC, 50/60 Hz
Terminal Block
Feed-through modular terminal block,
spring cage connection, 5.2 mm width
Wire Specification:
Wire Size/ Cross Section
110 VAC: 110 VAC: 8 AWG/10 mm
2
240 VAC: 12 AWG/4 mm
2
Current Consumption:
110 VAC
240 VAC
C1000S
40 A
18 A
C800S
33 A
15 A
C600S
26 A
12 A
