Installation Guide: Capstone C1000S/C800S/C600S with C1000 Series Controller
480064 Rev C (December 2018) Page 14 of 122
Capstone reserves the right to change or modify, without notice, the design, specifications, and/or contents of this document without
incurring any obligation either with respect to equipment previously sold or in the process of construction.
1.3. Disclaimer
Information in this publication represents data available at the time of print. Capstone Turbine
Corporation reserves the right to change this publication and the products represented without
notice and without any obligation or liability whatsoever.
All instructions and diagrams have been checked for accuracy and simplicity of application.
However, the skills of the installer are most important. Capstone Turbine Corp. does not
guarantee the result of any installation contained in this manual. Nor can Capstone Turbine Corp.
assume responsibility for any injury or damage to property. Persons engaging in installation do
so entirely at their own risk.
1.4. C1000S/C800S/C600S Models
The package design of each C1000S/C800S/C600S model is built around a number of 200 kW
microturbine bays. The C1000S contains five microturbine bays for 1000 kW output, the C800S
contains four microturbine bays for 800 kW output, and the C600S contains three microturbine
bays for 600 kW output. Most attributes of the turbine assembly other than power output are
identical across all models. Figure 1 shows the C1000S/C800S/C600S models in their respective
enclosures. Existing models also include the 800S and 600S in a five-bay package as shown in
Figure 2.
