8.2.1.2. E-Stop Installation
The E-Stop inputs are identified as Local and Global E-Stops. This enables connection to a local
E-Stop device for stopping a single C1000S/C800S/C600S assembly, and to a global E-Stop
device for stopping multiple assemblies. The E-Stop inputs in a C1000 series controller are simple
contact closures intended for dry contact circuits.
If no external E-Stop device is installed, the E-Stop pins on terminal block
TB1 must be jumpered.
See Figure 55. The E-Stop configuration options are as follows:
No E-Stop: Install jumper between local E-Stop terminals TB1-10 and TB1-11. Install
jumper between global E-Stop terminals TB1-12 and TB1-13.
Local E-Stop only: Install jumper between global E-Stop terminals TB1-12 and TB1-13,
and connect an E-Stop device to the local E-Stop pins TB1-10 and TB1-11.
Global E-Stop only (MultiPac configuration): Install jumper between local E-Stop
terminals TB1-10 and TB1-11, and connect an E-Stop device to global E-Stop terminals
TB1-12 and TB1-13. Wire the global E-Stop pins from one C1000 series controller to the
next in the MultiPac.
Local and Global E-Stop (MultiPac configuration): Remove jumpers and connect a local
E-Stop device and global E-Stop device to their respective TB1 pins. Wire the global
E-Stop pins from one C1000 series controller to the next in the MultiPac.
