2-SAFETYINFORMATION

2.Crushinghazard

PTIL13TLB1433AA3

3.Crushinghazard

PTIL13TLB1433AA4

4.Crushinghazard

PTIL13TLB1433AA5

5.Objectsfallinghazard

PTIL13TLB1434AA6
