Case 570T - Page 66

3-CONTROLSANDINSTRUMENTS
Dumpingwithbottomdumpbucket(iftted)
Withthebottomdumpbucketleverinreverseposition“5”,
thebucketopens(dumps).
PTIL13TLB1751AB7
Automaticreturntodig
Levermustbemovedtooat(position3)androllback
(position6)atthesametime,diagonaloperation.Ifmoved
totheindicatedposition“6”thebucketwillrollbackbutthe
loaderwillnotlower.
NOTE:Itispossibletoadjustthetiltangleforbucketlling.
PTIL12TLB0528AB8
Hydromechanicalself-leveling
Theselflevelinglinkagemountedontherighthandloader
armandframeautomaticallycontrolstheangleofthe
loaderbucketduringtheraisingcycleoftheliftarmsto
maintainaconstantbucketlevel.
Theselflevelingmechanism
Selflevelingbeginsatthepointwherethetube(2)onthe
loaderarmcontactsthewasheronthebellcrank(1)and
liftstheverticallinkagerod(3).
Thelinkagethenmovesthebucketcontrolvalveintothe
rolloutpositiontolevelthebucket.
PTIL13TLB0499AB9
3-24
