Case 921C - Rotating Beacon (if Equipped)

OPERATING INSTRUCTIONS
122
LEFT PAGE
Bur 6-34090EUR
ROTATING BEACON (IF EQUIPPED)
The rotating beacon control switch is
on the RH console. Push the top of the
switch for ON position and push the
bottom of the switch for OFF position.
BD02B055
Transport Position
To adjust the rotating beacon lamp to
the TRANSPORT poisiton, rotate the
lamp assembly and mounting bar
downward until the spring loaded
detents hold the lamp assembly and
mounting bar in the transport position
as shown in the following photo.
BD02B077
Operating Position
To adjust the rotating beacon lamp to
the OPERATING poisiton, rotate the
lamp assembly and mounting bar
upward until the spring loaded detents
hold the lamp assembly and mounting
bar in the operating position as shown
in the following photo.
BD02B080
