OPERATING INSTRUCTIONS
127
RIGHT PAGE
Bur 6-34090EUR
TRANSPORTING THE MACHINE
SB042
46-76C
84-13A
You must know the rules or laws for
transportation and safety that are used
in each area that you will be in. Make
sure that the truck and machine are
equipped with the correct safety
equipment.
1. Put a block at the front and rear of
each trailer wheel.
2. Be Careful, move the machine
SLOWLY onto the trailer.
3. Lower the loader bucket onto the
trailer.
4. Put the Transport/Service link in
the LOCKED position. .
BD00B021
5. Apply the parking brake and stop
the engine. Remove the key.
6. Make sure the transmission control
is in the NEUTRAL position and
loader controls are in the HOLD
position.
7. Turn the battery master disconnect
switch to the OFF position.
8. Put blocks at the FRONT and
REAR of each tire of the machine.
9. Use chains to fasten the machine
to the trailer. See the Next Page for
tie down locations of the machine.
10. Put a cover over the exhaust pipe.
11. Rotate the beacon to the
TRANSPORT position. See
beacon in this manual.
12. Measure from the ground to the
highest point of the machine. You
must know the clearance height of
the machine..
94F25
TIE DOWN DECAL
WARNING: The machine can slip and fall from a trailer or ramp and cause
injury or death. Make sure the trailer and ramp is not slippery. Remove all
oil, grease, ice, etc. Carefully move the machine off or onto the trailer with
the machine centered on the trailer and ramp.
WARNING: Before you put the machine on a trailer, remove all snow, ice,
oil or grease from the trailer and ramp.
WARNING: Know the rules, regulations, laws and safety equipment
necessary for transporting or operating this machine on a road or highway.
Rotating beacon, backup alarm, slow moving vehicle emblem and other
safety equipment items are available from your dealer.
To Next Page
