Case 921C - Master Disconnect Switch

INSTRUMENTS/CONTROLS
88
LEFT PAGE
Bur 6-34090EUR
MASTER DISCONNECT SWITCH
BD02B030
1. MASTER
DISCONNECT SWITCH
The Master Disconnect
Switch has two positions:
ON and OFF.
ON - This position
energizes the entire
electrical system. When
the master Disconnect
switch is ON and the key
switch is OFF, the
following electrical components have
power: dome lamp, horn, stop lamps,
four-way flashers and the rotary light
switch.
OFF - This position
disconnects all power to
the machine.
IMPORTANT:
DO NOT use the master
Disconnect Switch to stop the engine.
1
BS00A018
BS00A203
BS00A017
