Case 921C - FLUID LEVELS

LUBRICATION/FILTERS/FLUIDS
142
LEFT PAGE
Bur 6-34090EUR
LUBRICATION/MAINTENANCE CHART
NOTE 1:Service the air filter elements if the air filter warning lamp illuminates.
NOTE 2:Service the hydraulic filters if the hydraulic filter lamp illuminates.
NOTE 3:Every 10 hours of operation or once each day, whichever comes first.
NOTE 4:Check the dearation tank coolant level if the cooling level warning lamp illuminates.
NOTE 5:Service transmission filter if the transmission filter restriction warning lamp illuminates or
every 1000 hours (whichever comes first).
❉
- As Needed
P
A
G
E
N
O
.
SERVICE POINTS
N
O
.
O
F
P
O
I
N
T
S
FREQUENCY IN HOURS
C
H
E
C
K
C
L
E
A
N
L
U
B
R
I
C
A
T
E
D
R
A
I
N
W
A
T
E
R
156 Air Cleaner (See Note 1)
❉
167 Hydraulic Filter (See Note 2 ❉
203 Alternator Drive Belt ❉
204 Air Conditioning Compressor Belt Tension (If Equipped) ❉
173 Transmission Filter (See Note 5) ❉
153 Engine Oil Level (See Note 3) 10
174 Transmission Oil Level (engine running oil warm) 50
161 Dearation Tank Coolant Level (See Note 4) 50
146 Rear Axle Trunnion Pivots 2 50
174 Hydraulic Reservoir Fluid Level 50
146 Front Drive Shaft Support Bearing 50
146 Bucket Pivots 3 50
146 Steering Cylinder Pivots - Rod End 2 100
146 Steering Cylinder Pivots - Closed End 2 100
146 Loader Lift Arm and Cylinder Pivots 10 100
