INSTRUMENTS/CONTROLS
52
LEFT PAGE
Bur 6-34090EUR
INFORMATION CENTER
BD02B020
1. INFORMATION CENTER
You can display many of the machine functions on your Programmable
Information Center. It can be programmed to display all functions, or only the
functions that are important to you.
Here are the functions you may choose to see on your Information Center:
HOURMETER - Displays the accumulated running time of the engine in hours and
tenths of an hour with an “hour glass” symbol.
NOTE: Machine hour can be checked with out the key switch being in the ON
position, by pushing in and holding the right side of the program reset switch.
TACHOMETER - Displays the engine speed in revolutions per minute along with
an “n/min” symbol.
SPEEDOMETER - Displays the ground speed in either kilometers per hour (km/h)
or miles per hour (mph) along with either an “km/h or mph” symbol.
ENGINE COOLANT TEMPERATURE - Displays the engine coolant temperature
in Celsius with the engine coolant temperature bar graph flashing.
ENGINE OIL PRESSURE - Displays the engine oil pressure in kilo pascals (kPa)
with the engine oil pressure bar graph flashing.
FUEL LEVEL - Displays the fuel level in percent (%) remaining from a full tank
with the fuel level bar graph flashing.
A. UP COUNT C. PROGRAM
B. DOWN COUNT D. RESET
1
A
B
C
D
