OPERATING INSTRUCTIONS
124
LEFT PAGE
Bur 6-34090EUR
Transport and Carry Operation
The bucket must be in the roll back
position and the bottom of the bucket
must not be more than 305 to 457 mm
(12 to 18 inches) off the surface.
165L96
SA041
Operating on a Hill
Before you operate this machine on a hill, always put the transmission in a lower
range and test the brakes. DO NOT let the machine move down a hill with the
transmission in NEUTRAL. The transmission is in NEUTRAL when the left brake
pedal is pushed down and the left side of the declutch switch is pushed down.
Loader Control
The loader control levers are
connected to a hydraulic accumulator
through a pressure reducing valve. The
purpose of the reducing valve and
accumulator combination is to: (1)
allow the operator to lower the loader
arms if the engine stops with the loader
arms raised, or (2) give the control
system hydraulic pressure assistance
when operating the machine at low idle
speed. To test accumulator
performance, perform steps 1 through
5.
1. Start the engine.
2. Raise the loader bucket.
3. Stop the engine.
4. Turn the key to RUN.
5. Move the lift arm control to
LOWER. The loader bucket must
lower to the ground. If the bucket
does not lower to the ground, see
the Service Manual for this
machine or see your dealer.
WARNING: When you operate the machine, keep the loader bucket as
low as possible. This low position gives better balance and permits you to
see more clearly. If the bucket is full and you move the machine over
ground that is rough or surfaces that can cause the machine to slide,
always operate at slow speed. If you do not use this procedure, the
machine can go out of control and roll-over.
