INSTRUMENTS/CONTROLS
39
RIGHT PAGE
Bur 6-34090EUR
INSTRUMENT PANEL INDICATORS
BD02B020
3. LAMP INDICATOR:
This indicator illuminates when the lamp are ON.
4.
PILOT LOCKOUT INDICATOR
This indicator illuminates when the pilot lockout is actuated.
5.
LOW COOLANT INDICATOR:
This indicator illuminates when the engine coolant is low. The alarm
sounds continuously and the master indicator lamp will be red.
NOTE: Stop the engine and add coolant to the radiator.
6.
BRAKE PRESSURE INDICATOR:
This indicator illuminates when the brake system pressure is too low. The alarm
sounds continuously and the stop master indicator will be red.
NOTE: Stop the machine and correct the problem.
3
4
5
6
BS98M062
BC00B048
BC00B110
BC00B108
