INSTRUMENTS/CONTROLS
81
RIGHT PAGE
Bur 6-34090EUR
SIDE CONSOLE
BD02B022
2. WRIST REST:
Adjust the wrist rest to a comfortable height to operate the loader control levers.
3. ADJUSTMENT KNOB:
To adjust, loosen the adjustment knob and raise or lower the wrist rest to the
correct height. Tighten the knob.
4. HEAT CONTROL (IF EQUIPPED);
Turn the control clockwise for ON. Adjust the control to the needed
temperature. Turn the control completely counterclockwise for OFF
(see Recirculation Louvers in this manual). Select the desired fan
speed.
NOTE: Make sure the water inlet on the engine for the heater is in the full ON
position.
5. BLOWER FAN SWITCH (IF EQUIPPED):
The blower fan switch has four positions: OFF, 1, 2 and 3. Turn the
switch to 3 for maximum speed and to 1 for the slowest speed. Turn
the switch completely counterclockwise for OFF (see Recirculation
Louvers in this manual).
2
3
4
5
BC00B128
BC00B127
