Nominal Motor Voltage [221]
Set the nominal motor voltage, U
n_mot
.
Nominal Motor Frequency [222]
Set the nominal motor frequency.
Nominal Motor Power [223]
The range for P
n_mot
depends on the nominal softstarter
power P
n_soft
. It must be set within the range 25 - 400% of
the softstarter power Pn_soft. If parallel motors, set the sum
of the motor power. See nominal data for CG motors in Ta-
ble 27.
Default:
400 V for SI-units
460 V for US-units
Range: 100-700 V
Resolution 1 V
NOTE: The Motor Volts value will always be stored as a 3
digit value with a resolution of 1 V.
Default:
50 Hz for SI-units
60 Hz for US-units
Range: 50 or 60 Hz
221 Motor Volts
Stp M1: 400V
222 Motor Freq
Stp M1: 50Hz
Default: P
n_mot
Range:
25-400% x P
n_soft
, default see Table 27,
page 74.
Resolution 3 significant digits
Ta b l e 2 7 No m i n a l d a t a f o r CG m o tors complying to IE2 class
of IEC 60034-30.
Softstarter
nominal
current
[A]
Default
nominal
power
@ 400 V
SI-units
[kW]
Default
nominal
speed
@ 50 Hz
SI-units
[rpm]
Default
nominal
power
@ 460 V
US-units
[hp]
Default
nominal
speed
@ 60Hz
US-units
[rpm]
16 7.5 1,440 10 1,730
22 11 1,460 15 1,750
30 15 1,460 20 1,750
36 18.5 1,465 25 1,760
42 22 1,465 30 1,760
56 30 1,465 40 1,760
70 37 1,480 50 1,780
85 45 1,475 60 1,770
100 55 1,480 75 1,780
140 75 1,480 100 1,780
170 90 1,480 125 1,780
200 110 1,485 150 1,780
240 132 1,485 200 1,780
300 160 1,490 250 1,790
360 200 1,490 300 1,790
450 250 1,490 350 1,790
560 315 1,490 450 1,790
630 355 1,490 500 1,790
710 400 1,490 600 1,790
820 450 1,490 700 1,790
1,000 560 1,490 800 1,790
1,400 800 1,490 1,000 1,790
1,800 1,000 1,490 1,500 1,790
223 Motor Power
Stp M1: (P
n_mot
) kW
