Chroma 63800 Series User Manual

Measurements
4-11
Users can change the orders of the measurement parameters arbitrarily
under CONF/LOCAL  4. DISPLAY SELECTION, please refer section 3.4.1
Setting the Configuration.
4.2.4 Constant Power Mode
There are five measurement values under CP mode: V, I, P, V
overshoot
, and V
undershoot
. They
are shown as pages below.
Main page:
P
s
e
t
=
2
5
0
0
.
0
0
W
I
p
(
m
a
x
)
=
1
0
0
.
0
0
A
V = 0 . 0 0 P = 0 . 0 0
I = 0 . 0 0

D C
Second page:
P
s
e
t
=
2
5
0
0
.
0
0
W
I
p
(
m
a
x
)
=
1
0
0
.
0
0
A
V o v e r s h o o t = 0 . 0 0

V u n d e r s h o o t = 0 . 0 0
D
C
Users can change the orders of the measurement parameters arbitrarily
under CONF/LOCAL  4. DISPLAY SELECTION, please refer section 3.4.1
Setting the Configuration.
4.2.5 Rectified Load Mode
There are four measurement values under Rectified mode: V, I, P, and I
p
. They are shown
as pages below.
