Chroma 63800 Series User Manual

Remote Operation
8-9
Example : MEAS:POW?
MEASure[:SCALar]:POWer:AMPLitude:MAX?
FETCh[:SCALar]:POWer:AMPLitude:MAX?
Description: Return the peak power measured at the input of electronic load.
Query Syntax : MEASure[:SCALar]:POWer:AMPLitude:MAX?
FETCh[:SCALar]:POWer:AMPLitude:MAX?
Response Parameter: <NR2>
Example : MEAS:POW:AMPL:MAX?
MEASure[:SCALar] :POWer:APParent?
FETCh[:SCALar] :POWer:APParent?
Description: Return the apparent power being dissipated by the load in volt-amperes (VA).
Query Syntax : MEASure[:SCALar] :POWer:APParent?
FETCh[:SCALar] :POWer:APParent?
Response Parameter : <NR2>
Example : MEAS:POW:APP?
MEASure[:SCALar] :POWer:PFACtor?
FETCh[:SCALar] :POWer:PFACtor?
Description: Return the load power factor. The power factor is computed as:
power factor = real power / apparent power
Query Syntax : MEASure[:SCALar] :POWer:PFACtor?
FETCh[:SCALar] :POWer:PFACtor?
Response Parameter : <NR2>
Example : MEAS:POW:PFAC?
MEASure[:SCALar] :POWer:REACtive?
FETCh[:SCALar] :POWer:REACtive?
Description: These queries return the reactive component of the power being dissipated by
the load at the input terminals in VAR.
Query Syntax : MEASure[:SCALar] :POWer:REACtive?
FETCh[:SCALar] :POWer:REACtive?
Response Parameter : <NR2>
Example : MEAS:POW:REAC?
8.6.2.4 Resistance Measurement
MEASure | FETCh
[:SCALar]
: RESistance? Return the resistance in ohms
MEASure[:SCALar]:RESistance?
FETCh[:SCALar]: RESistance?
Description: Return the RESistance in ohms.
Query Syntax : MEASure[:SCALar] :RESistance?
FETCh[:SCALar] : RESistance?
Response Parameter: <NR2>
Example : MEAS:RES?
