Chroma 63800 Series User Manual

Programmable AC/DC Electronic Load 63800 Series Operation & Programming Manual
3-28
P
s
e
t
=
4
5
0
0
.
0
C
F
=
1
.
4
1
4
I
p
(
m
a
x
)
=
1
0
.
0
U
N
I
T
:
W
,
A
V = 0 . 0 0 P = 0 . 0 0
I = 0 . 0 0 S = 0 . 0 0

A
C
C
F
O
N
L
Y
3.8.3 PF Only
For switching PF only mode, the procedures are as below:
1. Press CONF./LOCAL key.
2. Press 1 , then press ENTER to enter SETUP. (The display please refer 3.8.1 BOTH
mode.)
3. Move the direction key ( ▲, ▼ ) to “1-5. CF/PF SETTING”.
4. Press the direction key ( ◄, ► ) or rotate the rotary knob to choose “PF”. (The display
please refer 3.8.1 BOTH mode.)
5. Then press CP to enter the PF only mode.
Users can press the arrow key to select the setting parameters on the LCD display, including
current RMS value, PF, and I
p
(max). Users can type the values of current, PF and I
p
(max) with
the Entry keys.
P
s
e
t
=
4
5
0
0
.
0
P
F
=
1
.
4
1
4
I
p
(
m
a
x
)
=
4
0
.
0
U
N
I
T
:
W
,
A
V = 0 . 0 0 P = 0 . 0 0
I = 0 . 0 0 S = 0 . 0 0

A
C
P
F
O
N
L
Y
