7-24 System testing
6200 Packet-Optical Platform Installation, Commissioning, and Testing Procedures
Release 1.1 009-6200-201 Draft Issue 1
Copyright
©
2014 Ciena
®
Corporation September 2014
Procedure 7-5 (continued)
Testing STM-1/4/16/64/OC-3/12/48/192 protection switching with traffic on 4xFE interfaces of 6G
PKT SW circuit pack
Step Action
Ethernet port testing (at the near and far end network elements in daisy-chain) and WAN interface
test ing (at the near and far end network elements) configured in 1+1 MSP/APS or SNCP/UPSR
mode
3 Create WAN associations between the Ethernet ports in 1+1 MSP/APS or
SNCP/UPSR mode as specified in Table 7-2 and Table 7-3 on page 7-25
respectively.
Table 7-2
For 1+1 MSP/APS mode
WAN STM/OC/ port
number must be
KLM value STS #, VT-Group, VT #
value
SDH SONET
1 1, 2 1-1-1 to 1-3-1 1-1-1 to 1-3-2
2 1, 2 1-3-2 to 1-5-2 1-3-3 to 1-5-4
3 1, 2 1-5-3 to 1-7-3 1-6-1 to 2-1-2
4 1, 2 2-1-1 to 2-3-1 2-1-3 to 2-3-4
5 1, 2 2-3-2 to 2-5-2 2-4-1 to 2-6-2
6 1, 2 2-5-3 to 2-7-3 2-6-3 to 3-1-4
7 1, 2 3-1-1 to 3-3-1 3-2-1 to 3-4-2
8 1, 2 3-3-2 to 3-5-2 3-4-3 to 3-6-4
