7-44 System testing

6200 Packet-Optical Platform Installation, Commissioning, and Testing Procedures

Release 1.1 009-6200-201 Draft Issue 1

2014 Ciena

Corporation September 2014

Procedure 7-9 (continued)

Testing STM-1/4/16/64/OC-3/12/48/192 protection switching with traffic on 2xGE(e) interfaces on

4xGE + 4xFE circuit pack

Action

Step Action

1 Connect the test equipment and the 6200 near and far 6200 network

elements as shown in Figure 7-9 on page 7-47.

2 Determine the type of protection required.

Ethernet port testing and WAN interface test (at the near and far end network elements)

configured in 1+1 MSP/APS SNCP/UPSR mode

3 Create WAN associations between the Ethernet ports in 1+1 MSP/APS or

SNCP/UPSR/UPSR mode as specified in Table 7-12 and Table 7-13

respectively.

4 Generate traffic with the Ethernet test set (150 Mbits/s,full duplex) and verify

that no packets are lost.

5 Record the data in the Table 12-6 on page 12-7. The result verifies that all the

Ethernet ports and optical ports function correctly.

If Then

1+1 MSP/APS is

required

Provision 1+1 MSP/APS group on the optical port,

both at the near and far end network elements.

Go to step 3 on page 7-44.

SNCP/UPSR is

required

Provision SNCP/UPSR on the optical port, both at the

near and far end network elements. Go to step 3 on

page 7-44.

Table 7-12

For 1+1 MSP/APS mode

where

WAN is

the STM/OC port

number must be

where S value (VC4/STS3C

container)/S-K (VC3/STS1 container)

SDH/SONET

1 1 1/1-1 to 1-3

Table 7-13

For SNCP/UPSR mode
