System testing 7-45
6200 Packet-Optical Platform Installation, Commissioning, and Testing Procedures
Release 1.1 009-6200-201 Draft Issue 1
Copyright
©
2014 Ciena
®
Corporation September 2014
Procedure 7-9 (continued)
Testing STM-1/4/16/64/OC-3/12/48/192 protection switching with traffic on 2xGE(e) interfaces on
4xGE + 4xFE circuit pack
Step Action
Testing protection switching on the Ethernet port
6 Determine your next step.
7 Click Submit.
A confirmation page is displayed. After confirming a success message is
displayed.
8 Connect the test set to a single Ethernet port.
9 Generate a loss of signal condition (LOS) on the working path by
disconnecting the fiber.
Traffic switches from the working to the protection path.
If protection mode
is of
Then
1+1 MSP/APS go to step 9.
SNCP/UPSR set the reversion mode as non-revertive or revertive
with max WTR time for each VC/VT in the WAN for the
Ethernet port under test.
