Procedure 10-6 (continued)
Installing and removing pluggable modules
Step Action
5 While holding the SFP/XFP module with the side where the electrical
connections are exposed to your left, slide the SFP/XFP module into one of
the receptacles in the circuit pack faceplate. See Figure 10-3 on page 10-16.
Note: The SFP/XFP module must slide easily into its receptacle until it locks
into place. If it does not slide easily, verify the orientation of the module. The
orientation of the module is different for XFP and SFP.
SFP LED indications
You have completed the installation of the pluggable module.
Removing a pluggable module
6 Determine your next step.
7 Perform a manual switching to switch traffic away from the SFP/XFP that is to
be replaced. Go to step 9 on page 10-15.
Refer to Provisioning and Protection Switching Procedures, 009-6200-310 for
details.
State Rx LED Tx LED
Power On: First LED activity noticed power-up. red red
SFP present (Laser on) with Rx LOS amber green
SFP present (Laser off) with Rx LOS amber off
SFP present (Laser on) with no Rx LOS green green
SFP present (Laser off) with no Rx LOS green off
SFP missing (LOS detected), Laser On (attempted) amber green
SFP missing (LOS masked since SFP missing and
set to Admin_down), Laser Off (attempted)
amber off
SFP failed (whether provisioned, unprovisioned,
LOS or no LOS)
red red
If the protection mode is Then go to
linear 1+1 MSP/APS step 8 on page 10-15
SNCP/UPSR step 7
