Common procedures 10-15
6200 Packet-Optical Platform Installation, Commissioning, and Testing Procedures
Release 1.1 009-6200-201 Draft Issue 1
Copyright
©
2014 Ciena
®
Corporation September 2014
Procedure 10-6 (continued)
Installing and removing pluggable modules
Step Action
8 Determine your next step.
9 Disconnect the fiber-optic cable from the pluggable module.
10 Swing open the latch on the SFP/XFP module to the bottom to disengage the
SFP module from the optical interface on the circuit pack. Open the bail latch
until it is perpendicular to the face of the SFP/XFP module.
11 Use the bail latch to carefully pull the SFP/XFP module out of its cage on the
optical interface. Make sure you apply the extraction force in a direction
parallel to the long dimension of the SFP/XFP module.
12 Place the pluggable module back into its ESD-protective packaging.
13 Clear the lockout protection/forced switch, issued at step 8, or the manual
switch request issued at step 7.
You have completed the removing of the pluggable module.
—end—
If you want to replace the Then
working SFP/XFP perform a force switch to protect,
then go to step 9.
protect SFP/XFP perform a lockout protection
switching, then go to step 9.
CAUTION
Risk of static damage
Wear an antistatic wrist strap and foot straps to protect
the shelf and the equipment from static damage.
Connect the wrist strap to an available earth point.
To Next Page
