44
The value can be indicated in tenths of
millimeter (dmm) or hundredths of inch
(inch) according to the unit of measurement
set in SETUP under the heading
“Configuration”.
That value is the distance between the left
edge of the tag and the left side of the
character.
For reasons due to the tag structure, in
order not to write on the hanging hole it is
advisable not to emboss below these values:
65 dmm (about 26 in inches) for Dog Tag
70 dmm (about 27 in inches) for Red Tag.
Box where the starting point of the field
along the Y axis coordinate is indicated.
The value can be indicated in tenths of
millimeter (dmm) or hundredths of inch
(inch) according to the unit of measurement
set in SETUP under the heading
“Configuration”.
That value is the distance between the lower
edge of the tag and the lower side of the
character.
For reasons due to the tag structure, it is not
possible to emboss below these values:
40 dmm (about 16 in inches) for both
Dog Tag and Red Tag.
Box where it is possible to choose the
number of characters of the field. It is not
possible to type in a value higher than the
one indicated beside.
It is (for example 20) the maximum value of
the number of characters beyond which
MAX cannot be set.
The value is automatically calculated on the
basis of the tag size, the starting point of the
field along the X axis and the spacing
between one character and the other.
Box where the type of field is defined.
Variable field where the data to be
embossed are entered.
The data can be entered
manually or loaded from a
data base.
Protected field with fixed text where
the contents cannot be
modified.
Counter field with counter function.
The number of the counters
used is assigned when
