A MACHINE SET UP
-21
OPERATOR’S MANUAL PRO SERIES
COLOR LOW LEVEL
(70...130) (90)
Intensity of the light levels.
Must be set by running a Card Test 45, ensuring that the
lightest grey levels are also made visible. The higher the
value, the darker the light levels.
COLOR CONTRAST
(70...130) (90)
Intensity of the colour.
Must be set by running a Card Test 45, ensuring that the
darkest level is as close to black as possible. The higher
the value, the higher the contrast.
X OFFSET SYNCHRO
(750...830) (775)
Distance in half-steps from the Photocell to the Printing
head 1= 0.042 mm.
Must be set by running a Card Test 46, ensuring that the
print starts on the card with a safety margin of 2 tenths
to prevent the ribbon from breaking. The higher the
value, the further the card moves before it is printed on.
Y OFFSET SYNCHRO
(0...2) (0)
Vertical offset: distance of the image origin from the
head origin (every section corresponds to lowering the
printing area by 16 DOT or 1.4 mm).
Must be set by running a Card Test 46, in accordance
with the margin that you want to leave between the
image and the upper edge of the card.
