6 TROUBLESHOOTING
6 - 4
OPERATOR’SMANUAL PRO SERIES
CODE MSG POSSIBILE INTERVENTO
E-06 Y MOTOR ERR.-
CHECK CARD/PRESS
START
Signals a movement error on the gripper Y axis. Check:
Photocell FC1 for proper functioning;
that there is nothing mechanical obstructing complete gripper strokes;
cleaning, lubrication and sliding on the guide;
correct positioning of mechanical limit stops;
that the set-up parameter settings match those indicated on the card
and in the operator’s manual
that the punching mask data are correct.
E-10 PAUSE EMBOSSING -
PRESS START
The machine is in the pause mode. Press START to continue.
E-12 ERROR IN TRACK 1 -
PRESS START
Writing or reading error on ISO 1 of magnetic strip.
Check the card and press Start to reset the error or feeder to repeat the
card. If the defect persists, clean the head, and check for proper card
movement in the encoding zone.
E-13 ERROR IN TRACK 2 -
PRESS START
Writing or reading error on ISO 2 of magnetic strip.
Check the card and press Start to reset the error or feeder to repeat the
card. If the defect persists, clean the head, and check for proper card
movement in the encoding zone.
E-14 ERROR IN TRACK 3 -
PRESS START
Writing or reading error on is 3 of magnetic strip.
Check the card and press Start to reset the error or feeder to repeat the
card. If the defect persists, clean the head, and check for proper card
movement in the encoding zone.
E-15 ERROR ENCOD.
COMMUNICATION -
PRESS START
There is no serial communication between the logic card and the
encoder card. Check the fuse on the encoder card;
ensure that the 5-Volt (regulator 7805) exists on card RS232;
ensure that all cables are properly connected.
E-16 NO INPUT FROM
ENCODER - PRESS
START
The encoder card is not returning any messages to the logic card.
Check the fuse on the encoder card;
ensure that the 5-Volt (regulator 7805) exists on card RS232;
ensure that all cables are properly connected.
E-17 NO INPUT FROM CARD
- PRESS START
No data are being read in code on the card.
Check whether the card was loaded properly;
check the magnetic strip for damage;
check that the encoding head has been properly connected and that no
wires are broken
E-18 OUT OF INFILL RIBBON
- REPLACE/START
Signals the lack or breakage of the infiller tape.
Mount a new one or repair the broken one;
check photocell FC6 for proper functioning.
