CIM PRO COMBI 1000 - 8.1 LINK WARE CONNECTIONS

8LIN
K
WARE CONNECTIONS
8-3
OPERATOR’S MANUAL PRO SERIES







8.1 LINK WARE CONNECTIONS
To link the machine in line with another Pro Series
machine there is the need of the base floor furniture
(optional) and the LINK-WARE software module
(optional) and proceed as follows.
• Switch on the machines, enter in the set-up
configuration parameter (refer to A MACHINE SET
UP) and modify the following parameters:
On the left hand side machine, when it receives
cards from another Pro Series machine:




MODULAR INPUT
(YES/NO) (YES)

On the right hand side machine, when it passes
cards to another Pro Series machine:
MODULAR OUTPUT
(YES/NO) (YES)

• Remember to configure the software correctly by
setting the machine address as indicated in the
protocol menu.
