Cisco 300 Series Administration Guide

Security: IPV6 First Hop Security
Configuring First Hop Security through Web GUI
432 Cisco Small Business 200, 300 and 500 Series Managed Switch Administration Guide (Internal Version)
20
STEP 4 Enter the following fields:
• Policy Name—Enter a user-defined policy name.
• Device Role—Select either Server or Client to specify the role of the device
attached to the port for the Neighbor Binding policy.
- Inherited—Role of device is inherited from either the VLAN or system
default (client).
- Client—Role of device is client.
- Host—Role of device is host.
• Neighbor Binding Logging—See above.
• Neighbor Binding Entry Limits—See above.
STEP 5 If required, click either Attach Policy to VLAN or Attach Policy to Interface.
Policy Attachment (VLAN)
To attach a policy to one or more VLANs:
STEP 1 Click Security > First Hop Security > Policy Attachment (VLAN).
The list of policies that are already attached are displayed along with their Policy
Type, Policy Name and VLAN List.
STEP 2 To attach a policy to a VLAN, click Add and enter the following fields:
• Policy Type—Select the policy type to attach to the interface.
• Policy Name—Select the name of the policy to attach to the interface
• VLAN List—Select the VLANs to which the policy is attached. Select All
VLANs or enter a range of VLANs.
STEP 3 Click Apply to add the settings to the Running Configuration file.

Cisco 300 Series Specifications

General

Model	Cisco 300 Series
Category	Switch
Dimensions	Varies by model
Weight	Varies by model
Power over Ethernet (PoE)	Available on select models
Management	Web-based GUI, SNMP, CLI
VLANs	Up to 256
Security Features	ACLs, 802.1X, Port Security
Humidity	10% to 90% non-condensing
Ports	8, 16, 24, 48
