Security: IPV6 First Hop Security
Configuring First Hop Security through Web GUI
Cisco Small Business 200, 300 and 500 Series Managed Switch Administration Guide (Internal Version) 433
20
Policy Attachment (Port)
To attach a policy to one or more ports or LAGs:
STEP 1 Click Security > First Hop Security > Policy Attachment (Port).
The list of policies that are already attached are displayed along with their
Interface number, Policy Type, Policy Name and VLAN List.
STEP 2 To attach a policy to a port or LAG, click Add and enter the following fields:
• Interface—Select the interface on which the policy will be attached.
• Policy Type—Select the policy type to attach to the interface.
• Policy Name—Select the name of the policy to attach to the interface
• VLAN List—Select the VLANs to which the policy is attached. Select All
VLANs or enter a range of VLANs.
STEP 3 Click Apply to add the settings to the Running Configuration file.
Neighbor Binding Table
To add or modify entries in the Neighbor Binding table:
STEP 1 Click Security > First Hop Security > Neighbor Binding Table
STEP 2 Select one of the following clear table options:
• Static Only—Clear all static entries in the table.
• Dynamic Only—Clear all dynamic entries in the table.
• All Dynamic & Static —Clear all dynamic and static entries in the table.
STEP 3 Click Add to add a new entry to the table.
STEP 4 Enter the following fields:
• VLAN ID—VLAN ID of the entry.
• IPv6 Address—Source IPv6 address of the entry.
• Interface Name— Port on which packet is received.
• MAC Address— Neighbor MAC address of the packet.
