Chapter 8 Monitoring the Cisco Unified IP Phone Remotely
Network Configuration
Network Configuration
The Network Configuration area on a phone’s web page displays network configuration information and
information about other phone settings. Table 8-2 describes these items.
You can view and set many of these items from the Network Configuration Menu and the Device
Configuration Menu on the Cisco Unified IP Phone. For more information, see Chapter 5, “Configuring
Features, Templates, Services, and Users.”
To display the Network Configuration area, access the web page for the phone as described in the
“Accessing the Web Page for a Phone” section on page 8-2, and then click the Network Configuration
hyperlink.
Table 8-2 Network Configuration Area Items
Item Description
DHCP Server IP address of the Dynamic Host Configuration Protocol (DHCP) server from which the
phone obtains its IP address.
BOOTP Server Indicates whether the phone obtains its configuration from a Bootstrap Protocol (BootP)
server.
MAC Address Media Access Control (MAC) address of the phone.
Host Name Host name that the DHCP server assigned to the phone.
Domain Name Name of the Domain Name System (DNS) domain in which the phone resides.
IP Address Internet Protocol (IP) address of the phone.
Subnet Mask Subnet mask used by the phone.
TFTP Server 1 Primary Trivial File Transfer Protocol (TFTP) server used by the phone.
Default Router 1–5 Default router used by the phone (Default Router 1) and optional backup routers (Default
Router 2–5).
DNS Server 1–5 Primary Domain Name System (DNS) server (DNS Server 1) and optional backup DNS
servers (DNS Server 2–5) used by the phone.
Operational VLAN ID Auxiliary Virtual Local Area Network (VLAN) configured on a Cisco Catalyst switch in
which the phone is a member.
Admin. VLAN ID Auxiliary VLAN in which the phone is a member.
