3-10
Cisco Unified IP Phone Administration Guide for Cisco Unified Communications Manager 7.1
OL-18913-01
Chapter 3 Setting Up the Cisco Unified IP Phone
Adjusting the Placement of the Cisco Unified IP Phone
Adjusting Cisco Unified IP Phone Placement on the Desktop
You can adjust the footstand adjustment plate on the Cisco Unified IP Phone to the height that provides
optimum viewing of the phone screen. See Figure 3-4 for more information.
Procedure
Step 1 Push in the footstand adjustment button.
Step 2 Adjust the footstand to desired height.
Securing the Phone with a Cable Lock
You can secure the Cisco Unified IP Phones 7962G, 7942G, 7961G, 7961G-GE, 7941G, and 7941G-GE
to a desktop by using a laptop cable lock. The lock connects to the security slot on the back of the phone,
and the cable can be secured to a desktop.
The security slot can accommodate a lock up to 20 mm. Compatible laptop cable locks include the
Kensington® laptop cable lock and laptop cable locks from other manufacturers that can fit into the
security slot on the back of the phone.
See Figure 3-3.
Figure 3-3 Connecting a Cable Lock to the Cisco Unified IP Phones 7962G, 7942G, 7961G,
7961G-GE, 7941G, and 7941G-GE
144477
