Cisco 7962G Administration Guide

4-20
Cisco Unified IP Phone Administration Guide for Cisco Unified Communications Manager 7.1
OL-18913-01
Chapter 4 Configuring Settings on the Cisco Unified IP Phone
Device Configuration Menu
Line Settings Menu for SIP Phones
The Line Settings menu displays information that relates to the configurable parameters for the lines on
your SIP phone. Table 4-9 describes the options in this menu.
Related Topics
• Displaying a Configuration Menu, page 4-2
• Device Configuration Menu, page 4-16
Call Preferences Menu for SIP Phones
The Call Preferences menu displays settings that relate to the settings for the call preferences on the SIP
phone. Table 4-10 describes the options in this menu.
Table 4-9 Line Settings Menu Options
Option Description To Change
Name Displays the lines and the number used to register each
line.
Use Cisco Unified Communications
Manager Administration to modify.
Short Name Displays the short name configured for the line. Use Cisco Unified Communications
Manager Administration to modify.
Authentication Name Displays the name used by the phone for authentication
if a registration is challenged by the call control server
during initialization.
Use Cisco Unified Communications
Manager Administration to modify.
Display Name Displays the identification the phone uses for display
for caller identification purposes.
Use Cisco Unified Communications
Manager Administration to modify.
Proxy Address Displays the IP address of the proxy server that will be
used by the phone. The value is left blank because it is
not applicable to SIP phones that are using Cisco
Unified Communications Manager.
Display only—cannot configure.
Proxy Port The value is left blank because it is not applicable to
SIP phones that are using Cisco Unified
Communications Manager.
Display only—cannot configure.
Shared Line Displays if the line is part of a shared line (Yes) or not
(No).
Display only—cannot configure.
Table 4-10 Call Preferences Menu Options
Option Description To Change
Caller ID Blocking Indicates whether caller ID blocking is enabled
(Yes) or disabled (No) for the phone.
From Cisco Unified Communications
Manager Administration, choose Device >
Device Settings > SIP Profile.
Anonymous Call Block Indicates whether anonymous call block is enabled
(Yes) or disabled (No) for the phone.
From Cisco Unified Communications
Manager Administration, choose Device >
Device Settings > SIP Profile.

Cisco 7962G Specifications

General

Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Case material	ABS
Product color	Black, Grey
Wall mountable	Yes
Bluetooth	No
Security algorithms	128-bit AES, 802.1x RADIUS
Networking standards	IEEE 802.1Q, IEEE 802.1p, IEEE 802.1x, IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Ethernet LAN (RJ-45) ports	2
Voice codecs	G.711, G.711a, G.722, G.729A, G.729ab, iLBC
Volume control	Digital
Display diagonal	5 \
Display resolution	320 x 222 pixels
Display number of colors	Monochrome
Caller ID	-
Lines quantity	- lines
Phonebook capacity	- entries
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Number of handles included	1 pc(s)

Weight and Dimensions

Depth	203.2 mm
Width	266.7 mm
Height	152.4 mm
Weight	1600 g
