Cisco 7962G Administration Guide

4-23
Cisco Unified IP Phone Administration Guide for Cisco Unified Communications Manager 7.1
OL-18913-01
Chapter 4 Configuring Settings on the Cisco Unified IP Phone
Device Configuration Menu
NTP Configuration Menu for SIP Phones
The NTP Configuration menu displays information about the NTP server and mode configuration used
by SIP phones. Table 4-13 describes the options on this menu.
User Locale Char
Set
Character set that the phone uses for the user
locale.
Display only—cannot configure.
Network Locale Network locale associated with the phone user.
The network locale identifies a set of detailed
information that supports the phone in a specific
location, including definitions of the tones and
cadences used by the phone.
From Cisco Unified Communications Manager
Administration, choose Device > Phone > Phone
Configuration.
Network Locale
Ve rs i o n
Version of the network locale loaded on the
phone.
Display only—cannot configure.
NTP Configuration
(SIP phones only)
Menu to view information on NTP server and
mode configuration. For more information, see
NTP Configuration Menu for SIP Phones,
page 4-23.
From Cisco Unified Communications Manager
Administration, choose System > Phone NTP
Reference.
Table 4-12 Locale Configuration Menu Options (continued)
Option Description To Change
Table 4-13 NTP Configuration Menu Options
Option Description To Change
NTP IP Address 1 IP address of the primary NTP server. From Cisco Unified Communications Manager
Administration, choose System > Phone NTP
Reference.
NTP IP Address 2 IP address of the secondary or backup NTP
server.
From Cisco Unified Communications Manager
Administration, choose System > Phone NTP
Reference.
NTP Mode 1 Primary server mode. Supported modes are
Directed Broadcast, Unicast, Multicast, Any cast.
From Cisco Unified Communications Manager
Administration, choose System > Phone NTP
Reference.
NTP Mode 2 Secondary server mode. Supported modes are
Directed Broadcast, Unicast, Multicast, Any cast.
From Cisco Unified Communications Manager
Administration, choose System > Phone NTP
Reference.

Cisco 7962G Specifications

General

Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Case material	ABS
Product color	Black, Grey
Wall mountable	Yes
Bluetooth	No
Security algorithms	128-bit AES, 802.1x RADIUS
Networking standards	IEEE 802.1Q, IEEE 802.1p, IEEE 802.1x, IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Ethernet LAN (RJ-45) ports	2
Voice codecs	G.711, G.711a, G.722, G.729A, G.729ab, iLBC
Volume control	Digital
Display diagonal	5 \
Display resolution	320 x 222 pixels
Display number of colors	Monochrome
Caller ID	-
Lines quantity	- lines
Phonebook capacity	- entries
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Number of handles included	1 pc(s)

Weight and Dimensions

Depth	203.2 mm
Width	266.7 mm
Height	152.4 mm
Weight	1600 g
