Cisco 7962G Administration Guide

A-5
Cisco Unified IP Phone Administration Guide for Cisco Unified Communications Manager 7.1
OL-18913-01
Appendix A Providing Information to Users Via a Website
How Users Configure Personal Directory Entries
Step 6 Choose the directory in which you want to install the application and click Next.
The Ready to Install window displays.
Step 7 Click Install.
The installation wizard installs the application to your computer. When the installation is complete, the
InstallShield Wizard Complete window displays.
Step 8 Click Finish.
Step 9 To complete the process, follow the steps in the “Configuring the Synchronizer” section on page A-5.
Configuring the Synchronizer
Step 1 Open the Cisco Unified IP Phone Address Book Synchronizer.
If you accepted the default installation directory, you can open the application by choosing Start > All
Programs > Cisco Systems > TabSync.
Step 2 To configure user information, click the User button.
The Cisco Unified CallManager User Information window displays.
Step 3 Enter the Cisco Unified IP Phone user name and password and click OK.
Step 4 To configure Cisco Unified Communications Manager server information, click the Server button.
The Configure Cisco Unified CallManager Server Information window displays.
Step 5 Enter the IP address or host name and the port number of the Cisco Unified Communications Manager
server and click OK.
If you do not have this information, contact your system administrator.
Step 6 To start the directory synchronization process, click the Synchronize button.
The Synchronization Status window provides information on the status of the address book
synchronization. If you chose the user intervention for duplicate entries rule and you have duplicate
address book entries, the Duplicate Selection window displays. Choose the entry that you want to include
in your Personal Address Book and click OK.
When synchronization completes, click Exit to close the Cisco Unified CallManager Address
Book Synchronizer. To verify if the synchronization worked, log in to your User Options web pages and
choose Personal Address Book. The users from your Windows address book should be listed.

Cisco 7962G Specifications

General

Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Case material	ABS
Product color	Black, Grey
Wall mountable	Yes
Bluetooth	No
Security algorithms	128-bit AES, 802.1x RADIUS
Networking standards	IEEE 802.1Q, IEEE 802.1p, IEEE 802.1x, IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Ethernet LAN (RJ-45) ports	2
Voice codecs	G.711, G.711a, G.722, G.729A, G.729ab, iLBC
Volume control	Digital
Display diagonal	5 \
Display resolution	320 x 222 pixels
Display number of colors	Monochrome
Caller ID	-
Lines quantity	- lines
Phonebook capacity	- entries
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Number of handles included	1 pc(s)

Weight and Dimensions

Depth	203.2 mm
Width	266.7 mm
Height	152.4 mm
Weight	1600 g
