4-6
Cisco Unified IP Phone Administration Guide for Cisco Unified Communications Manager 7.1
OL-18913-01
Chapter 4 Configuring Settings on the Cisco Unified IP Phone
Network Configuration Menu
For information about the keys you can use to edit options, see the “Editing Values” section on page 4-3.
Table 4-2 Network Configuration Menu Options
Option Description To Change
IPv4 Configuration Internet Protocol v4 address menu.
In the IPv4 Configuration menu, you can do the following:
• Enable or disable the phone to use the IPv4 address
that is assigned by the DHCPv4 server.
• Manually set the IPv4 Address, Subnet Mask, Default
Routers, DNSv4 Server, and Alternate TFTP servers
for IPv4.
For more information on the IPv4 address fields, refer to
the specific field within this table.
1. Unlock network configuration
options.
2. Scroll to IPv4 Configuration and
press the Select softkey.
IPv6 Configuration Internet Protocol v6 address menu.
In the IPv6 Configuration menu, you can do the following:
• Enable or disable the phone to use the IPv6 address
that is assigned by the DHCPv6 server or to use the
IPv6 address that it acquires through Stateless
Address Autoconfiguration (SLAAC).
• Manually set the IPv6 Address, Subnet Prefix Length,
DNSv6 Server, and IPv6 TFTP Servers.
For more information on the IPv6 address fields, refer to
Table 4-4.
For more information on SLAAC, refer to Deploying IPv6
in Unified Communications Networks with Cisco Unified
Communications Manager 7.1.
1. Unlock network configuration
options.
2. Scroll to IPv6 Configuration and
press the Select softkey.
MAC Address Unique Media Access Control (MAC) address of the
phone.
Display only—Cannot configure.
Host Name Unique host name that the DHCP server assigned to the
phone.
Display only—Cannot configure.
