D15362.06 DX70 and DX80 Administrator Guide CE9.2, NOVEMBER 2017. www.cisco.com — Copyright © 2017 Cisco Systems, Inc. All rights reserved.
64
Cisco DX70 and DX80 Administrator Guide
Sign in to the web interface and navigate to Maintenance >
User Interface Screenshots.
Capture user interface screenshots
Delete screenshots
If you want to delete all screenshots,
click Remove all.
To delete just one screenshot, click
the
×
button for that screenshot.
Capture a screenshot
Click Take screenshot of OSD to capture a
screenshot of the on-screen display.
The screenshot displays in the area below
the buttons. It may take up to 30 seconds
before the screenshot is ready.
All captured snapshots are included
in the list above the buttons. Click the
screenshot ID to display the image.
About user interface
screenshots
You can capture screenshots of the on-
screen display (menus, indicators and
messages on the main display).
