4023074 Rev B Model D9858 Advanced Receiver Transcoder Installation and Operation Guide 4-53
Setup Menu: Outputs: TS Out: MOIP1, Continued
Output Mode
Description: This selects the DPM output mode.
Parameters: No Output, Passthrough, Service Channels Only, MAP
Passthrough, MAP Svc Chans Only or Full DPM Control.
These
settings are described in the table below.
Note: If you change any of the DPM parameters while in MAP Passthough, MAP
Svc Chans Only or Transcoding Output Modes, the Output Mode will change to
Full DPM Control. Full DPM Control is primarily used for manual control, but uses
the last set of DPM settings prior to changing the mode.
Note: When changing any DPM parameter in either MAP Passthough, MAP Svc
Chans or Transcoding Output Modes, you will prompted with a “Resync All”
message. If you choose No, the transcoder will use the current settings in which
case, if the PMT content has been changed, the input to output PID mapping will be
lost; however, if you choose Yes, the transcoder will use the new PMT content.
Output Mode Description
No Output No ASI or MPEGoIP output will be generated.
Passthrough The output will be identical to the input. The output
channel will not be modified.
PE/PID remapping options, PSI regeneration and User
Rate are not supported in this mode.
Service Channels
Only
Only service channels will be output.
MAP Passthrough The output will be identical to the input, except that it
will be generated using the DPM and PID mapping
settings.
MAP Svc Chans
Only
Only service channels will be output according to the
DPM and PID mapping settings.
Full DPM Control The output will be generated according to the DPM
settings on the DPM: ASI or MOIP1 menus. This is a
manual control setting.
Transcoding The output will be generated using the DPM default
settings, except that the DPM action (Act) will be set to
Xcode and the Descramble Mode will be set to
Descrambled.
To Next Page
