8 Mounting/removing front attachment
8.2 Installing the front attachment
67084
70769
8.2.4 Connecting the hydraulic system
– Observe the general warnings at the beginning of
the Fitting / removing the front attachment
chapter.
– Connect the male couplings with a colour
marking (1) to the corresponding female
couplings (A/B/C).
70791
8.2.5 Connecting the electric equipment
(accessory)
– Observe the general warnings at the beginning of
the Fitting / removing the front attachment
chapter.
10
14540
11
19528
1
A
B
C
Caution!
Machine operation with polluted utilities.
Machine damage.
– Ensure that no dirt will get into the
removed lines.
– Ensure a clean environment.
Connection Colour
A colourless
B * red
C * blue
* (accessory)
